MS CEW TUBE 8mm OD X 1.5mm Thickness

Name: MS CEW TUBE 8mm OD X 1.5mm Thickness
Brand: CAPITAL TUBES INDIA
Price: 58.0 INR
Availability: InStock

Price 58.0 INR/ Meter

Get a Price/Quote

MS CEW TUBE 8mm OD X 1.5mm Thickness Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1000 Per Day

Delivery Time
3 Days

Main Domestic Market
All India

About MS CEW TUBE 8mm OD X 1.5mm Thickness

*Cold Extended Welded (CEW) tubes, also known as CDW (Cold Drawn Welded), are high-precision steel tubes manufactured through a meticulous cold-drawing process. Starting as electric resistance welded (ERW) tubes, they are pulled through a die and over a mandrel at room temperature. This process significantly enhances the tubea s mechanical properties, resulting in superior dimensional accuracy, a high-quality surface finish, and increased tensile strength. Because the drawing process eliminates the internal weld bead, CEW tubes offer exceptional concentricity and uniformity. They are the preferred choice for demanding industrial applications such as hydraulic cylinders, shock absorbers, automotive axles, and precision engineering components where tight tolerances and durability are non-negotiable.

Key Characteristics

Manufacturing Process: Starts as a standard ERW tube, then cold-drawn at room temperature to achieve exact wall thicknesses and diameters.
Superior Weld Strength: Cold drawing improves the weld seam, allowing it to reach >95% of the parent material's strength.
Precision: Offers high dimensional accuracy and exceptional surface finish, often reducing the need for costly secondary machining.
Typical Specifications

Standards: Commonly manufactured to specifications like IS 3074 (specifically grades CEW 1 through CEW 5 for automotive purposes).
Size Range: Outer diameters generally range from 6 mm to 114.3 mm, with wall thicknesses varying between 0.5 mm and 20 mm.
Length: Standard lengths are usually 6 meters, or custom-cut to specification.

Common Applications

Automotive: Used for shock absorbers, steering columns, exhaust systems, and structural components.
Industrial & Machinery: Hydraulic equipment, material handling devices, and precision machined parts.

Superior Cold Drawn Precision

The MS CEW Tube is manufactured using the advanced cold drawn process, ensuring smooth surface finish, consistent dimensions, and increased tensile strength. Our tubes meet strict industry tolerances of +/-0.2mm, making them perfect for precision applications in machinery, automotive, and hydraulic systems. The combination of annealing and oil treatment further enhances durability and longevity.

Enhanced Surface Protection

With an annealed and oiled surface, our mild steel CEW tubes provide excellent resistance to corrosion and wear during storage and use. Each tube is fitted with a robust metal pipe cap to prevent end damage during transport and handling, ensuring that the product arrives in optimal condition to the customer.

FAQ's of MS CEW TUBE 8mm OD X 1.5mm Thickness:

Q: How is the MS CEW Tube 8mm OD x 1.5mm Thickness manufactured?

A: This tube is produced using the cold drawn technique, which improves dimensional accuracy, surface finish, and mechanical properties compared to conventional manufacturing processes.

Q: What are the benefits of the annealing and oiled surface treatment?

A: Annealing relieves internal stresses and enhances ductility, while the oiled finish provides additional protection against corrosion, ensuring a longer lifespan for the tube.

Q: Where can the MS CEW Tube be used effectively?

A: These tubes are ideal for applications in automotive, construction, machinery, and hydraulic systems where high precision and durability are required.

Q: What purpose does the metal pipe cap serve on the ends of each tube?

A: The metal pipe cap acts as an end protector, safeguarding the tube ends from impacts and contamination during transit and storage.

Q: How does the tolerance of +/-0.2mm benefit your projects?

A: The tight tolerance ensures consistent dimensions across all tubes, reducing assembly time and improving fitment in precision-engineered systems.

Q: When should MS CEW Tubes with these specifications be chosen over other options?

A: Select these tubes when your project demands high dimensional accuracy, enhanced mechanical properties, and reliable surface protection for moderate load-bearing applications.
